Description
Channels: 1 in/2 out (3 out) (configurable as 2 in/3 out)
Architecture: Analog Devices SigmaDSP® 50 MIPS internal
Data processing: 28-bit data path, 56-bit internal processing latency 1.02 ms fixed latency architecture
User data storage: Up to 4 local presets, unlimited pass-through
Control: software
Interfaces: USB
Audio
Frequency response: 20 Hz - 20 kHz (-0.5 dB)
Maximum input voltage: 8.2 V / +20 dBu
Maximum output voltage: 4.1 V / +14.3 dBu
S/N ratio (analog-to-analog) > 113 dB
THD+N < 0.02% (20 Hz - 20 kHz)
DSP features
Delay: 340 ms input delay ,10 ms output delay per channel
Input EQ : 5 parametric EQs: Peak, High/Low Shelf, Allpass, Bandpass, Bandstop, High/Lowpass
Output EQ: Parametric IIR filters: Peak, High/Lowshelf, Allpass, Bandpass, Bandstop, High/Lowpass
Crossover filters :Butterworth, Linkwitz-Riley, Bessel, 6dB/oct to 48dB/oct
Limiter : Peak limiter, RMS limiter ,Frequency deviation limiter, Clip limiter, Temperature limiter
Parameter lock :OEM/user function protection
AD/DA converter
Architecture: AKM 24 bit @ 48 kHz
Dynamic range AD/DA: 118 dB / 114 dB
THD+N < 0.01% (20 Hz - 20 kHz)
